Belt conveyor is an common equipment in conveying materials. Widely used in food plants, chemical plants, building materials, ports, light industry and other industries.
It is economical and convenient for you. It has simple structure and low noise, also it can operate smoothly and reliable for you to convey bulk materials and irregular stuff.
Belt conveyor is with large capacity, low operating cost and wide application. There are fixed and mobile conveyor according to support structure; There are belt conveyor,plastic belt conveyor and steel belt conveyor according to the transporting materials .
Belt conveyor is a common means of transport used in mining enterprises. It uses the belt conveyance to draw and support components and transport materials by way of the moving belt. It utilizes the inner friction and side pressure of loose material to increases the internal pressure from the pulling force in its moving direction produced by the rolling chamber in the adhesive chamber, thus increasing the internal friction. When inclination falls within certain scope, the inward friction force can ensure the stability between layers and create continuous movement. When the internal friction force between the layers is larger than the external force of the adhesive, the roller beneath the adhesive will move along with the material. When the ratio of internal force and external force meets a condition, the material flow is stable.
Working temperature is between -10 ℃ and +40 ℃ and the raw material temperature can not exceed 70 ℃. Heat-resistant rubber belt can transport the high-temperature materials ( below 120 ℃ ) and the belt conveyor is not suggested when the raw material with higher temperature.
We can also supply the resistant-oil,resistant-acid,resistant-alkali rubber belt or plastic belt conveyor. There are six conveyor belt width: 500, 650, 800, 1000, 1200 and 1400mm. Users can require the layout of the conveyor and belt width, canvas layer and belt thickness according to various factors such as conveying height, the type of material, capacity and transport length.
| Section Type | Belt speed | Belt width B(mm) | |||||
|---|---|---|---|---|---|---|---|
| 500 | 650 | 800 | 1000 | 1200 | 1400 | ||
| Capacity G(t/h) | |||||||
| Groovetype | 0.8 | 78 | 131 | ||||
| 1.0 | 97 | 164 | 278 | 435 | 655 | 891 | |
| 1.25 | 122 | 206 | 348 | 544 | 819 | 1115 | |
| 1.6 | 156 | 264 | 445 | 696 | 1048 | 1427 | |
| 2.1 | 191 | 323 | 546 | 853 | 1284 | 1748 | |
| 2.5 | 232 | 391 | 661 | 1033 | 1556 | 2118 | |
| 3.15 | 824 | 1233 | 1858 | 2528 | |||
| 4.0 | 2202 | 2996 | |||||
| Flat type | 0.8 | 41 | 67 | 118 | |||
| 1.0 | 52 | 88 | 147 | 230 | 345 | 469 | |
| 1.25 | 66 | 110 | 184 | 288 | 432 | 588 | |
| 1.6 | 84 | 142 | 236 | 368 | 553 | 753 | |
| 2.0 | 103 | 174 | 289 | 451 | 677 | 922 | |
| 2.5 | 125 | 211 | 350 | 546 | 821 | 1117 | |
| Length (m) | 15 | 30 | 45 | 60 | 100 | 150 | 200 | 300 | |
|---|---|---|---|---|---|---|---|---|---|
| Belt width(mm) | 500 | 1.0 | 1.3 | 1.7 | 2.0 | 3.2 | 4.6 | 8.0 | 11.1 |
| 650 | 1.3 | 1.9 | 2.4 | 2.8 | 4.6 | 9.2 | 11.5 | 16.0 | |
| 800 | 1.9 | 2.9 | 3.6 | 4.3 | 9.7 | 14.0 | 17.5 | 24.3 | |
| Belt wide(mm) | 500 | 650 | 800 | 1000 | 1200 | 1400 | |
|---|---|---|---|---|---|---|---|
| Body widthmm | Head frame | 1000-1010 | 1150-1160 | 1410-1470 | 1610-1630 | 1860-1880 | 2120-2130 |
| Screw tight end frame | 800 | 960 | 1180 | 1410 | 1660 | 1860 | |
| Middle frame | 870 | 1020 | 1220 | 1440 | 1690 | 1860 | |
| Belt heightmm | head wheel | 800-2250 | 800-2315 | 800-2400 | 935-2500 | 950-2500 | 100-2500 |
| End wheel | 800 | 800 | 800 | 1000 | 1000 | 1000 | |
| Middle section | 800 | 800 | 800-1000 | 1000-1200 | 1000 | 1200 | |
